CV JOINT CHALLENGE

Learn how automated and reproducible processes bring reliable and fast hardness test results for a surface hardened CV joint.

Solution

A reliable, fast and reproducible process of smart clamping, semi-automated grinding and polishing as well as fully automated hardness testing on especially the spline and ball tracks was developed consisting of:

Precision cutting with Axitom-5 and smart clamping setup to avoid pinching of cut-off wheel
A semi-automated and mechanical 4-step grinding and polishing process with AbraPol-30 to prepare surface for hardness testing
A fully automated CHD-measurement of 15 indentations with Duramin-40AC1

Tell us who you are and you may download a materialographic solution report of one of our many method solutions. Please don’t hesitate to contact us if you have a specific problem that you would like us to help you with.
